Dock Jetty Pneumatic Rubber Fender Yokohama Inflatable Anti Collision

Product Categories
Hongruntong Marine Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Dock Jetty Pneumatic Rubber Fender Yokohama Inflatable Anti Collision

Brand Name : DockFender

Model Number : DF-YRF3.5M

Certification : PIANC2014,ISO17357

Place of Origin : CHINA

MOQ : 1

Price : $116-$160

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 1650 PCS Per Month

Delivery Time : 8 Work Days

Packaging Details : Pallet, Wooden Case

Product Name : Dock pneumatic jetty yokohama rubber fender inflatable anti-collision with best quality

Material : High Density Natural Rubber

Standard : ISO17357-1:2014, PIANC2014

Part : Yokohama Floating Fender

Type : pneumatic Marine rubber Fenders

Certificate : CCS.ABS.LRS.BV.GL.DNV.NK

Lifespan : 6-10 years

Delivery : 7-10 days

Initial Internal Pressure : 0.05MPa/0.08MPa

Contact Now

Dock pneumatic jetty yokohama rubber fender inflatable anti-collision with best quality

Description

Yokohama fenders are a type of marine fender that are used to protect vessels and docks from collisions. They are made from high-quality rubber and have a unique design that allows them to absorb impacts and distribute the force evenly. Yokohama fenders are commonly used in ports, harbors, and offshore facilities. They come in various sizes and shapes to suit different types of vessels and docking requirements.

Yokohama fenders are a type of marine fender used to protect ships and docks from impact damage. They are made of high-quality rubber and have a cylindrical shape that allows them to absorb and distribute the energy of collisions. Yokohama fenders are known for their durability, reliability, and ease of installation, and they are commonly used in ports, harbors, and offshore facilities around the world.

Dock Jetty Pneumatic Rubber Fender Yokohama Inflatable Anti Collision

Specifications

Product Name Dock pneumatic jetty yokohama rubber fender inflatable anti-collision with best quality
Brand Name DockFender
Model Number DF-3.3*6.5M
Material High Density Natural Rubber
Standard ISO17357-1:2014, PIANC2014
Shape Cylindrical
OEM / ODM Welcome
Size As per drawing dimensions
Tolerance Standard ISO2768-M or ISO3302-1:2014 CLASS M2
Usage For ship docking or berthing
Certificate DNV BV CCS LR ABS
Color Customers' Requirements
Working Temperature -15 degreee to 200 degree

Fender Size Initial Pressure 50kPa
Performance Data		 Initial Pressure 80kPa
Performance Data

Diameter x

Length
[mm]

 Reaction Force
/ kN		 Energy Absorption
/ kNm		 Hull Pressure
at GEA
/ kN / m2		 Reaction Force
/ kN		 Energy Absorption
/ kNm		 Hull Pressure
at GEA
/ kN / m2
500 x 1,000 6 64 132 8 85 174
600 x 1,000 8 74 126 11 98 166
700 x 1,500 17 137 135 24 180 177
1,000 x 1,500 182 32 122 239 45 160
1,000 x 2,000 257 45 132 338 63 174
1,200 x 2,000 297 63 126 390 88 166
1,350 x 2,500 427 102 130 561 142 170
1,500 x 3,000 579 153 153 761 214 174
1,700 x 3,000 639 191 128 840 267 168
2,000 x 3,500 875 308 128 1,150 430 168
2,500 x 4,000 1,381 663 137 1,815 925 180
2,500 x 5,500 2,019 943 148 2,653 1,317 195
3,300 x 4,500 1,884 1,175 130 2,476 1,640 171
3,300 x 6,500 3,015 1,814 146 3,961 2,532 191
3,300 x 10,600 5,257 3,067 158 6,907 4,281 208
4,500 x 9,000 5,747 4,752 146 7,551 6,633 192
* Other size can be produced follow client's requirements.

Dock Jetty Pneumatic Rubber Fender Yokohama Inflatable Anti Collision

Fender Selection

Model Selection of Pneumatic Fender for Small & Middle Size Ship

Ship Tonnage(T) Recommendation Size D x L ( m) Ship Type
50 0.5 x1.0 Fishing ship
100 0.7 x 1.5~1.0 x 1.5 Fishing ship
200 1.0 x 1.5~1.2 x 2.0 Fishing ship, towing ship
300-500 1.2 x 2.0~1.5 x 2.5 Fishing ship, towing ship
1000 1.5 x 2.5~1.5 x 3.0 Towing ship, cargo ship
3000 2.0 x 3.0~2.0 x 3.5 cargo ship, ocean trawler
10000 2.0 x 3.5~2.5 x 4.0 cargo ship

Model Selection of Pneumatic Fender for Large-tonnage Ship

Ship

Tonnage

Assumed

Boarding Speed

Effective

Kinetic Energy

Fender Size

D*L
(DWT) (M/S) (KN.M) (m)
200000 0.15 1890 3.3 x 6.5
150000 0.15 1417 3.3 x 6.5
100000 0.15 945 3.0 x 5.0
85000 0.17 1031 3.0 x 6.0
50000 0.18 680 2.5 x 5.5
40000 0.2 672 2.5 x 5.5
30000 0.22 609 2.5 x 4.0
20000 0.25 525 2.5 x 4.0
15000 0.26 425 2.5 x 4.0
10000 0.28 329 2.0 x 4.0
5000 0.33 228 2.0 x 3.5
